Bed Thermocouple
Bed Thermocouple
Thermocouple Sensor
| Parameter | Specification |
|---|---|
| Type | K (Cr/Al) |
| Make | Aavad |
| Model | AKFD |
| Configuration | Duplex |
| Total no. of wires | 2 + 2 |
| Material of construction | Inconel-600 compacted MgO insulation |
| Protection head | Die-cast aluminum flameproof head with threaded cap & chain |
| Head protection class | IP-67 |
| Head cable entry connection | 1/2 " Npt |
| No. of cable entry | Double |
| Terminal block | Nickel-plated ceramic terminal block |
| Moc | Inconel 600 |
| Inset od | 8 mm |
| Outer od | 22 mm |
| Length | 450 mm |
Description
-
Fluid Bed Thermocouple With Metal Protection Tube Assambly
A thermocouple produces a temperature-dependent voltage as a result of the thermoelectric effect, and this voltage can be interpreted to measure temperature.
