AKCS-6S10-8
Fast Response Thermocouple
Fast Response Thermocouple
Thermocouple Sensor (QRT)
| Parameter | Specification |
|---|---|
| Type | K (Cr/Al) |
| Make | Aavad |
| Model | AKCS-6S108 |
| Configuration | Simplex |
| Temperature range | 1000℃ |
| Material of construction | SS 310 |
| Insulation | Compacted MgO insulation |
| Process connection | BSP |
| Process connection size | 1/2 ” (M) Adjustable |
| Od | 6 mm |
| Length | 1000 mm |
Description
- There are three types of thermocouple junctions: exposed, grounded or ungrounded. An exposed junction will provide the fastest response times. However, if the probe will be exposed to corrosive gas or high pressure, an exposed junction should not be used.
