K Type Thermocouple With Extension Wire
K Type Thermocouple With Extension Wire
Thermocouple Sensor
| Parameter | Specification |
|---|---|
| Type | K (Cr/Al) |
| Make | Aavad |
| Model | AKED |
| Configuration | Duplex |
| Temperature range | 0 To 600℃ |
| Material of construction | SS 316 |
| Insulation | Compacted MgO insulation |
| Process connection | BSP |
| Process connection size | 1/2 '' (M) Adjustable |
| Cable length | 1 Meter |
| Cable type | Teflon/Teflon |
| Sensor od | 6 mm |
| Sensor length | 300 mm |
Description
- Type K thermocouple is made when a wire of Nickel-Chromium is welded to a wire of Nickel-Alumel. The grade of the wire is dependent not only on the combination of alloys used, but also on the purity of those alloys.
