MTG-6"
Mercury Steel Temperature Gauge
Mercury Steel Temperature Gauge
6″ Mercury In Steel Type Temperature Gauge
| Parameter | Specification |
|---|---|
| Make | Aavad |
| Dial Size | 150 mm |
| Range | -30 To 50 Deg C |
| Case & Bezel | SS304, Bayonet Type |
| Socket | Ss304 Bourdon Tube’s 316 |
| Dial | Aluminum, Black Markings On White Background |
| Pointer | Aluminum, Black Over-Range Protection: 130% Of FSD |
| Accuracy | + /- 1.6% Of FSD |
| Joint | Argon Arc Welded |
| Window | Acrylic Glass |
| Mounting | Direct Bottom Connection |
| Connection | 1/2" Bsp (M) Adj. |
| Armour Capillary | No |
| Stem Od × Length | 8 × 150 mm |
Description
- A liquid-in-metal thermometer in which mercury is enclosed in a steel envelope. The change in internal pressure caused by the temperature variation is measured by a Bourdon tube that is connected to the mercury by a capillary tube.
