APMS
Miniature Head RTD Sensor
Miniature Head RTD Sensor
Mini Head RTD Sensor
| Parameter | Specification |
|---|---|
| Type | PT-100 |
| Make | Aavad |
| Model | APMS |
| Configuration | Simplex |
| Accuracy | Class A |
| Temperature range | -50 To 400℃ |
| Material of construction | SS 316 |
| Protection head | Miniature |
| Process connection | BSP |
| Process connection size | 1/2” (M) Adjustable |
| No. of cable entry | Single |
| Terminal block | Nickel Plated ceramic terminal block |
| Od | 6 mm |
| Length | 300 mm |
Description
- RTD probe with miniature aluminum protection head and screw-on cap with chain includes PT100 Ω platinum RTD element or PT1000 RTD element, 1/2″ NPT mounting threads and sheath of 316 stainless steel.
