N Type Thermocouple
N Type Thermocouple
Thermocouple
| Parameter | Specification |
|---|---|
| Type | N (Nicrosil/Nisil) |
| Make | Aavad |
| Model | ANIS |
| Configuration | Simplex |
| Total no. of wires | 2 |
| Element Dia. | 3.2 mm/10SWG |
| Temperature range | Up to 1200°C |
| Protection head | Die-cast aluminum flameproof head with threaded cap & chain |
| Head protection class | IP-67 |
| Head cable entry connection | 1/2 ” Npt |
| No. of cable entry | Single |
| Terminal block | Nickel-plated ceramic terminal block |
| Sheath moc | SS 310 |
| Inner sheath | Ceramic tube Ker-710 |
| Inner sheath od | 18 mm |
| Od X Id | 30 x 20 mm |
| Length below head | 1900 mm |
Description
- Type N. Type N (Nicrosil–Nisil) thermocouples are suitable for use between −270 °C and +1300 °C, owing to its stability and oxidation resistance.
