RTD With Fixed Connection
RTD With Fixed Connection
| Parameter | Specification |
|---|---|
| Type | PT-100 |
| Make | Aavad |
| Model | APWS-6×75 |
| Configuration | Simplex |
| Accuracy | Class A |
| Temperature range | -50 To 400℃ |
| Material of construction | SS 316 |
| Insulation | Compacted MgO insulation |
| Process connection | 1/2 ” BSP (M) fix fitting |
| Protection head | Die-Cast aluminum head with threaded cap & chain |
| Head protection class | IP-65 |
| Head cable entry connection | ¾ “Et |
| No. of cable entry | Single |
| Terminal block | Nickel-plated ceramic terminal block |
| Od | 6 mm |
| Length below head | 75 mm |
Description
RTD Probe with Fixed Process Connection temperature sensor has a fixed process connection thread making installation easier than with a compression fitting design thus making it ideal in OEM applications where assembly time is critical. The sensor is suitable for the measurement of liquids and gases across a wide temperature range. All sensors are made to order so it is generally possible to meet all of your requirements.
