S Type Exposed Thermocouple
Exposed Thermocouple Sensor
| Parameter | Specification |
|---|---|
| Type | S (Pt-Pt/Rh10%) |
| Make | Aavad |
| Model | ASES |
| Junction | Exposed |
| Configuration | Simplex |
| Temperature range | 0 To 1000℃ |
| Material of construction | Ceramic ker-710 |
| Insulation | Compacted MgO insulation |
| Cable length | 1 Meter |
| Cable type | Fiberglass/Fiberglass/SS |
| Sensor length | 300 mm |
| Sensor od | 5.5 mm |
Description
- Type S Thermocouple (Platinum Rhodium – 10% / Platinum): The Type S is used in very high temperature applications. It is commonly found in the BioTech and Pharmaceutical industries. It is sometimes used in lower temperature applications because of its high accuracy and stability.
