AKWS-I6S
Spring Loaded Thermocouple
Spring Loaded Thermocouple
Mi Spring Loaded Thermocouple
| Parameter | Specification |
|---|---|
| Type | K (Cr/Al) |
| Make | Aavad |
| Model | AKWS-I6S |
| Configuration | Simplex |
| Temperature range | 0 To 850℃ |
| Material of construction | Inconel 600 |
| Insulation | Compacted MgO insulation |
| Process connection | BSp |
| Process connection size | 1/2 ” (M) adjustable |
| Protection head | Die-Cast aluminum head with threaded cap & chain |
| Head protection class | IP-65 |
| Head cable entry connection | ¾ “Et |
| No. of cable entry | Single |
| Terminal block | Nickel Plated ceramic terminal block with spring-loaded |
| Od | 6 mm |
| Length | 850 mm |
Description
- Spring loaded thermocouples feature spring loaded sensor probes made using a metal or alloy sheath. These are one of the important variants of mineral insulated thermocouples, and they use a spring that helps create positive contact between the process and the tip. This positive contact will help accelerate the response time of the sensor and provides a more accurate reading of temperature. Thus, it is widely used in applications that demand accurate temperature measurement. Aavad Instrument offers spring loaded thermocouples that are designed for use with thermowells. They are also ideal for applications that require spring action.
