PWFM-S
SS Paddle Wheel Flow Sensor
SS Paddle Wheel Flow Sensor
Paddle Wheel Flow Meter
| Parameter | Specification |
|---|---|
| Fitting | SS fitting with welded flanged |
| Display | Led (flow rate/total flow) |
| Supply | 230Vac |
| Accuracy | 1% of full-scale deflection |
| Protection rating | IP-65 |
| Operating temp | up to 100°C for SS sensor |
| Operating pressure | 0 to 10 kg/cm2 |
| Flow range | 3.5 m3/hr to 35 m3/hr |
| Cable length | 5 Meter |
| Body | SS 304 |
| Paddle | PVDF |
| O ring | Viton |
Description
- Paddlewheel-type flow sensor in a compact housing. This sensor works on faraday’s law of electromagnetic induction. It generates a frequency & signal proportional to the flow. The sensor gives excellent and reliable results in the flow velocity range of 0.5 m/sec to 5 m/sec & for the flow with Reynolds no greater than 5000.
